Description
Digitrax LocoMotion™ System
Your locomotives look like the real thing. The Digitrax LocoMotion™ System makes them run like the real thing, too!
Torque Compensation for smooth as silk silent operation.
- 128 Speed Step operation (14 or 28 steps can also be used).
- Momentum with acceleration and deceleration.
- Normal Direction of Travel is user selectable.
- Switching Speed feature for easier and faster access to yard speeds.
- 3 Step Speed Tables set start, mid and max voltage for custom control.
- 28 Step Speed Tables with 256 level resolution for precise control.
- SuperSonic™ motor drive for silent operation.
FX3 Function outputs for prototypical lighting effects and on/off control:
- Constant Brightness Lighting with directional or independent control
- Realistic Effects like Ditch lights, Mars lights, strobes, and many more.
- FX3 & Standard Function Qualifiers operate functions based on direction, F0 on or off, direction and F0, and whether loco is moving.
- Function Remapping for custom function setup.
- Master Light Switch turns off all lights & functions with one keystroke.
- Advanced Consist Function Controls
- Decoder Lock equipped
– Transponder equipped ready for transponding on your layout.
– All Mode Programming with Operations Mode Read Back reads back CV values right on the mainline.
– Decoder Reset CV with or without speed table reset.
– Motor Isolation Protection prevents damage to your decoder.
– Basic, Advanced & UniVersal Consisting
– 2 Digit and 4 Digit Addressing
– DCC Compatible
– FCC Part 15, Class B RFI compliant
